SBI521 Service Manual 53
4.3.4 Misc Menu
Figure 4.4 MISC Menu Chart
The figure above is an illustration of the available menus with the MISC menu. There
are no programming choices within this menu. Refer to
Table 4.5 for explanations of
the menu choices.
Table 4.5 MISC Menu Choices and Explanations
4.3.5 Test Menu
Figure 4.5 TEST Menu Chart
The figure above is an illustration of the available menus with the TEST menu. There
are no programming choices within this menu. Refer to
Table 4.6 for explanations of
the menu choices.
Table 4.6 TEST Menu Choices and Explanations
CODE VOL DATE TIME VER COM2.TY
MISC
Submenu1 Remark
CODE Display ADC's code, this code can be after no-filter, filter1 or filter2
VOL Display voltage; calibrate voltage; set full charged voltage and low battery voltage
DATE Display date and set date
TIME Display time and set time
VER Display firmware version
COM2.TY Display interface type of COM2
DISP COM1.RD COM1.TD COM2.RD COM2.TD KEY
TEST
Submenu1 Remark
DISP Test LCD or LED
COM1.RD Test COM1 receiving
COM1.TD Test COM1 transmitting
COM2.RD Test COM2 receiving
COM2.TD Test COM2 transmitting
KEY Test keys and buzzer
