SBI521 Service Manual 45
Table 4.3 User Menu Choices and Explanations
USER
SubMenu1 SubMenu2 Option Default Parameter Description Comment
RESET NO NO Reset User menu parameters to
default setting
YES
COM1 BAUD.RT 1200 9600 Select COM1 baud rate
2400
4800
9600
19200
38400
57600
BYT.FMT 8N1 8N1 Select COM1 byte format (1)8N1=8 data bits, No parity
check bit, 1 stop bit
7O1 (2)7O1=7 data bits, 1 Odd parity
check bit, 1 stop bit
7E1 (3)7E1=7 data bits, 1 Even parity
check bit, 1 stop bit
OUT.MOD CONT PRT.CMD Select COM1 output mode (1)CONT=continuously output
PRINT (2)PRINT=output after [PRINT]
key is pressed
CMD (3)CMD=output after a request
command is received
PRT.CMD (4)PRT.CMD= output after
[PRINT] key is pressed or
request command received
STABLE (5)STABLE=output after scale is
stable; Note: use PRINT or CMD
to output data, the scale must be
stable
LAYOUT MULTPL MULTPL Set COM1 content and format (1)MULTPL= the following
selected item in OUT1 will be
output use defined format
SINGLE (2)SINGLE= only displayed
content and current status will be
output, it's compatible with NCI-
SCP01
200S (3)200S, 200F= only displayed
content and current status will be
output
200F
