SBI521 Service Manual 47
COM2 BAUD.RT 1200 9600 Select COM2 baud rate
2400
4800
9600
19200
28800
57600
BYT.FMT 8N1 8N1 Select COM2 byte format (1)8N1=8 data bits, No parity
check bit, 1 stop bit
7O1 (2)7O1=7 data bits, 1 Odd parity
check bit, 1 stop bit
7E1 (3)7E1=7 data bits, 1 Even parity
check bit, 1 stop bit
OUT.MOD CONT PRT.CMD Select COM2 output mode (1)CONT=continuously output
PRINT (2)PRINT=output after PRINT
key pressed
CMD (3)CMD=output after a request
command is received
PRT.CMD (4)PRT.CMD= output after PRINT
key pressed or request command
received
STABLE (5)STABLE=output after scale is
stable; Note: use PRINT or CMD
to output data, the scale must be
stable
LAYOUT MULTPL MULTPL Set COM2 content and format (1)MULTPL= the following
selected item in OUT2 will be
output use defined format
SINGLE (2)SINGLE= only displayed
content and current status will be
output, it's compatible with NCI-
SCP01
200S (3)200S, 200F= only displayed
content and current status will be
output
200F
LC.ADDR 00-99 01 Local address for COM2
EN.ADDR NO NO Enable or disable COM2 local
address in output or input
strings
YES
USER
SubMenu1 SubMenu2 Option Default Parameter Description Comment
