SBI521 Service Manual 63
6.5.2 Multiple
Caution
l
The decimal point position is determined by the CONFIG-PRIM.D
parameter.
l
The unit position and bytes is determined by which current unit is used.
l
The details of refer to the content in 4.3USER Submenu.
l
If USER-COM2-EN.ADDR is set to NO, no will be output.
l
In hold mode, if ADC conversion speed is set to high speed (80Hz), USER-
COM1/2-LAYOUT is set to MULTIPLE and many transmissions are selected
to output, the output contents from COM1 or COM2 may not catch up with
the data processed in indicator, If you want to watch real time data, you need
to select fewer output contents and set higher baud rate for COM1 or 2.
Example Layouts
When USER-OUT1/2-xxxx is set to YES (USER-COM2-EN.ADDR=No):
Weighing Mode:
Output string frame
W
1
W
2
W
3
W
4
W
5
W
6
U
1
U
2
U
3
U
4
U
5
---- Line number and content are determined by setting of USER-OUT1/2-xxxx
H
1
H
2
H
3
H
4
---- USER-OUT1/2-STATUS is set to YES
--- USER-OUT1/2-LINE is set to LINE1/2/3/4
---The number of blank lines is determined by USER-OUT1/2-LINE setting
--- Last byte of string frame
SCALE ID: 123456
GROSS: 123lb 4.56oz
TARE: 11lb 2.22oz
NET: 112lb 2.34oz
ACC. N: 8
TOTAL: 789lb 15.2oz
DATE: 2011-06-12
TIME: 12:34:56
A/D CODE: 1234567
VOLTAGE: 6.7V
STATUS: bpq2
