SBI521 Service Manual 7
1.4 Connections
The rear cover of the stainless steel enclosure must first be removed to make the
appropriate connections to the weigh platform, printer, remote display and power
supply.
To gain access to the connectors, remove the rear panel screws on the back of the
indicator.
Figure 1.1 Back View of Indicator
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer’s instructions.
ATTENTION: Il y a danger d'explosion s'il y a remplacement incorrect de la
batterie, remplacer uniquement avec une batterie du même type ou d'un type
équivalent recommandé par le constructeur. Mettre au rebut les batteries
usagées conformément aux instructions du fabricant.
Power Com 1/2 Loadcell
Config/Cal Switch Seal
Power Com 1/2 Loadcell
with back cover without back cover
