1
Chapter 1 Introduction
AVerDiGi MOB1304 is a 4-channel stand-alone DVR unit for mobile solution that can be
installed on the vehicle for security monitoring. It provides real-time monitoring and digital
recording of surveillance video. Up to 4 video cameras and 4 sensor devices can be hooked up
to this DVR unit. It also provides one audio input and output channel
.
DVR unit can be controlled through LCM with remote control. Also, With the On-Screen-Display
(OSD) menu, user can customize video recording setting, sensor and alarm settings, password
protection, hard drive recycling, and more.
Surveillance video is recorded in high-quality MPEG4 format. Three recording modes are
supported; D1 Enhanced Mode can record video from each video camera in higher resolution at
30/25 fps and D1 Mode can record video from each video camera in higher resolution at 60/50
fps and CIF Mode can record video in lower resolution and up to 120/100 fps (NTSC/PAL).
1.1 Package Contents
(1)
(2)
(3)
(4)
(5) (6)
(7)
(8)
(9)
(1) AVerDiGi MOB1304 unit
(2) Remote control (batteries are included)
*image of remote control just for reference only
(3) USB cable
(4) Software CD (User Manual and Quick Guide are included)
(5) Z-bracket x 2 (including 4 screws)
(6) Removable hard disk drawer accessories (with spare screws)
(7) Power cable
(8) SATA cable
(9) IR sensor extended cable
