OSD MENU Description
GENERAL SETUP
RECORD MODE
TIME STAMP
DVR NAME
WATERMARK
PRE RECORD
AUTO RECORD
CIF
COMPANY
00 SEC
DVR NAME
Assign a name for the DVR unit. Maximum is 10 characters may
contain A~Z, 0~9, !,
“, #, $, %, &, „, (, ), *, +, -, /, :, ;, <. >, ?, @, and
space.
TIME STAMP
Enable/disable the time and date display on the each channel.
AUTO RECORD
Enable/disable auto continue recording when interrupted (i.e., power
breakdown, video playback or configuration setup). It starts to record
after 5 second of idleness. This is applicable in Always Record mode.
PRE RECORD
Set the pre-recording time in seconds when alarm has occurred.
CHANNEL SETTING SETUP
120 / 120 FPS
RECORD
ENABLE
AUDIO RECORD
PREVIEW
CH1 CH2 CH3 CH4
MAX. FPS 30 30 30 30
FPS 30 30 30 30
QUALITY BEST BEST BEST BEST
FPS(ALARM) 30 30 30 30
QUALITY(ALARM) BEST BEST BEST BEST
ENCRYPTION
CHANNEL SETTING
Configure the parameters of each channel.
ENABLE
Enable/disable the channel to display the video on the surveillance
screen. If the channel is disabling, there won
‟t be any video display
and recording.
RECORD
Enable/disable the channel number to record video.
i The channels are enabled in the INSTALLATION can be set
for video recording.
AUDIO RECORD
Enable/disable audio recording. To record sound, make sure the
audio input device (ex: microphone) is connected to the DVR unit.
PREVIEW
Enable/disable the video preview on the surveillance screen.
MAX. FPS
Display the maximum frame rate of recording that user can configure.
Maximum fps total value depends on the RESOLUTION that user has
chosen.
FPS
Set the number of frames per second to be recorded. The higher the
frame rate, it uses more hard disk space.
QUALITY
Select the video quality setting from BEST, HIGH, GOOD, MEDIUM,
NORMAL or LOW. Choosing higher quality allows user to record less
hours but the quality of the recorded video is better.
FPS(ALARM)
Set the number of frames per second to be recorded when alarm has
occurred.
The higher the frame rate, it uses more hard disk space.
QUALITY(ALARM)
Select the video quality (BEST, HIGH, GOOD, MEDIUM, NORMAL or
LOW) of alarm recording. Choosing higher quality allows user to
record less hours but the quality of the recorded video is better.
Current total fps
value that user
has set Total fps value that
user can set
