If your TV does not have audio/video input terminals (Europe):
Use the RU-100 RF Unit to connect the camera to the television, then select the video channel:
Connecting the RF unit
1. Connect the RF unit to the camera.
2. Connect the aerial cable to the FROM
ANT. terminal on the RF unit.
3. Connect the ‘female’ DIN-connector on
the coaxial cable to the TO TV terminal
on the RF unit.
4. Connect the ‘male’ connector to the
aerial input on the TV.
To watch a TV programme
Turn the camera off or disconnect it from the RF
unit when you want to watch a broadcast
programme. If you leave the camera connected
and turned on, the RF unit will automatically select
the camera signal instead of the broadcast signal.
Selecting the video channel
W~1
00
(ft
o
o
■o
0)
o
G I
The video channel is the channel (somewhere
between 30 and 39) which is not used by a
broadcasting station in your area and can be used
for cassette playback.
1. Turn the TV on.
2. Start playback on the camera.
• See p. 15 for playback.
3. Set the G/l selector on the RF unit.
• Use a flat-edge screwdriver.
• In continental Europe, set it to G.
• In the U.K., Hong Kong and South Africa, set it
to I.
• If it is not set properly, you will be able to see
the picture, but not hear the sound,
4. Set the TV and the CH selector on the
RF unit to the video channel.
• For example, if the video channel in your area
is channel 33, tune the TV to channel 33 and
set the selector to 33 (using a flat-edge
screwdriver). Adjust it by turning until the
picture is clear.
• The selector is factory-set to channel 32.
