Inserting a Tape
Make sure that the battery pack or other power source is attached.
1
Press the small blue button
on the EJECT knob and
simultaneously slide it
down.
The cassette compartment
automatically lifts up and opens
toward you.
EJECT
Insert a tape with the window
facing out.
Close the cassette holder by
pressing the area on the
cassette holder marked
“PUSH”.
Preventing Accidental Erasure
To prevent accidental erasure, slide the tab on the cassette to expose the red mark.
To re-record on this tape, slide the tab opening the window.
If you try to record with the red mark exposed, the and 6 indicators blink in the
viewfinder and the display window and you will hear beep sounds for about five seconds.
icrl—
Notes on handling tapes
Do not insert anything in the small holes on the rear of the cassette. These holes are
used to sense the type and thickness of tape, or if the red mark is exposed or covered,
etc. Store tapes in their cases and keep them in an upright position to protect them from
dust and uneven windino.
