Editing

Editing Tapes with a VCR

You can edit a tape if you have an additional @ 8mm, fB Betamax or iVHS VHS format VCR

Original tape

Edited tape

This portion is not edited.

/------------------------s

'yj.ji' ■

Pause

Connecting the camcorder

Make connections using the supplied A/V cable and set the CHARGEA/TR selector on the

AC power adaptor to VTR. Set the input selector of the VCR to LINE, if available.

r~r

rjt

—r ‘p

AUDIO IN Ann VIDEO IN

(L.R)

AN connecting cable supplied

to AUDIO (L,R)

OUT

rSignal flow

The Video and Audio jacks on the connecting adaptor are used for output video and audio
signals only. The camcorder does not record through these jacks.
