OPERATING
INSTRUCTIONS
1. Heater must be properly installed before operation.
2. Rotate the thermostat knob fully clockwise. This should
energize the heating elements and fan causing warm air to
flow from the hot air discharge at the openings in the bottom
of the grille. (see note 5)
3. After the operation check, rotate the thermostat knob to the
desired position to obtain room comfort.
4. For continuous fan-only operation (heating elements will not
be energized), slowly rotate the thermostat knob clockwise
until you hear the fan operate (about 30 degrees from the
OFF point).
5. There will be a short delay from the time the unit is turned on
until the fan engages. This is to allow the elements time to
warm up. The fan will also continue to run once the unit is
turned off to allow the elements time to cool.
NOTE: For best results, the heater should be left “ON”
constantly during the heating season because the thermostat,
when properly set, will maintain the desired temperature.
How To Reset Manual Thermal Overheat
Protector Control:
Your heater is equipped with a manual reset thermal overheat
protector control that will automatically turn the heater off to
prevent a fire if the heater overheats. This control is located on
the fan panel assembly between the element and fan blade and
marked “
RESET”. The red reset button can be seen through the
front grille when the heater is installed. To reset, allow the heater
to cool, then push the red button that is visible through the hole
in the fan panel. The heater should immediately return to normal
operation.
MAINTENANCE
INSTRUCTIONS
It is important to keep this heater clean. Your heater will give you
years of service and comfort with only minimum care. To assure
efficient operation follow the simple instructions below.
User Cleaning Instructions:
1. After the heater has cooled, a vacuum cleaner with brush
attachment may be used to remove dust and lint from
exterior surfaces of the heater including the grille openings.
2. With a damp cloth, wipe dust and lint from grille and exterior
surfaces.
3. Return power to heater and check to make sure it is
operating properly.
Maintenance Cleaning Instructions:
(To be performed only by Qualified Service Personnel)
At least annually, the heater should be cleaned and serviced by
a qualified service person to assure safe and efficient operation.
This should include the removal of the grille and, as necessary
the heater from the backbox to clean residue from the unit. After
completing the cleaning and servicing, the heater should be fully
reassembled and checked for proper operation.
CAUTION - DO NOT CONTINUE TO ATTEMPT TO USE THE
HEATER IF THE SAFETY CONTROL REPEATEDLY
OPERATES AFTER BEING RESET. TO DO SO COULD
PERMANENTLY DAMAGE THE HEATER OR CREATE A
FIRE OR SAFETY HAzARD.
DO NOT TAMPER WITH OR BYPASS ANY SAFETY LIMITS
INSIDE HEATER.
ALL SERVICING BEYOND SIMPLE CLEANING THAT
REqUIRES DISASSEMBLY SHOULD BE PERFORMED BY
qUALIFIED SERVICE PERSONNEL.
TO REDUCE RISK OF FIRE AND ELECTRIC SHOCK OR
INJURY, DISCONNECT ALL POWER COMING TO HEATER
AT MAIN SERVICE PANEL AND CHECK THAT THE ELEMENT
IS COOL BEFORE SERVICING OR PERFORMING
MAINTENANCE.
