Installing System Components
83
Cable Routing
Cables that extend through the system front-to-back are routed along a cable
path within the interior right wall of the system chassis. The cables are
secured by a cable retention bracket that attaches to the inner wall.
Removing the Cable Retention Bracket
1 Remove the cooling shroud. See "Removing the Cooling Shroud."
2 Remove the cooling fan bracket. See "Removing the Fan Bracket."
3 Press outward on the blue release latch on the cable retention bracket and
slide the bracket back until the tabs at the bottom of the bracket clear the
chassis. See Figure 3-11.
4 Lift the cable retention bracket off the chassis wall.
