72
Installing System Components
Replacing a Hard-Drive Carrier
Removing a Hard Drive From a Hard-Drive Carrier
1 If you are removing a SATA hard drive from a SATAu drive carrier, remove
the interposer card:
a Viewing the hard drive carrier from the rear, locate the release lever on
the left end of the interposer card.
b Push the lever away from the carrier rail to release the left end of the card.
c Rotate the left end away from the hard drive to release the connector.
d Pull the right end of the interposer card clear of the slots in the carrier rail.
2 Remove the four screws from the slide rails on the hard-drive carrier and
separate the hard drive from the carrier.
Installing a SATA Hard Drive Into a SATA Drive Carrier
NOTE:
SATA hard drives that connect directly to the SAS backplane must be
installed in SATA drive carriers (labeled "SATA").
1 Insert the SATA hard drive into the hard-drive carrier with the connector
end of the drive at the rear. See Figure 3-5.
2 Align the screw holes on the hard drive with the holes on the hard-drive
carrier. See Figure 3-5.
3 Attach the four screws to secure the hard drive to the hard-drive carrier.
See Figure 3-5.
