66
Installing System Components
3 Rotate the left end of the bezel away from the system to release the right
end of the bezel.
4 Pull the bezel away from the system. See Figure 3-2.
Figure 3-2. Removing the Front Bezel
Replacing the Front Bezel
To replace the front bezel, perform the above steps in reverse.
Opening and Closing the System
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1 bezel lock 2 control panel LCD
2
1
