About Your System
13
Front-Panel Features and Indicators
Figure 1-1 shows the controls, indicators, and connectors located behind the
optional rack bezel on the system's front panel.
Figure 1-1. Front-Panel Features and Indicators
Option is displayed only if you have PXE support enabled through the
System Setup Program (see "Integrated Devices Screen" on page 51).
This keystroke allows you to configure NIC settings for PXE boot.
For more information, see the documentation for your integrated NIC.
If you have the optional Dell Remote Access Controller (DRAC), this
keystroke allows access to selected DRAC configuration settings. See the
DRAC User’s Guide for more information on setup and use of DRAC.
Table 1-1. Keystrokes for Accessing System Features (continued)
Keystroke Description
6 5 4 2 1 8 7 3
