188 Installing System Components
Internal Hard-Drives
The sled supports up to two 2.5-inch hard-drives attached internally to the
sled tray.
Removing a Hard-Drive Carrier
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
CAUTION: Combining SATA and SAS hard-drives in the same sled configuration
is not supported.
1 Remove the sled from the enclosure. See "Removing a Sled" on page 143.
2 Remove the back cover. See "Removing the Back Cover" on page 150.
3 Loosen the thumbscrew securing the hard-drive carrier to the hard-drive
bracket. See Figure 3-34.
4 Slide and lift the hard-drive carrier out of the sled tray. See Figure 3-34.
Figure 3-34. Removing and Installing a Hard-Drive Carrier
1
2
