Figure 3-20, See figure 3-20 – Dell PowerEdge C8000 User Manual
Page 170
170
Installing System Components
Figure 3-20. Removing and Installing the RAID Battery Assembly
6 Pry one end of the RAID battery and pull the battery straight out of the
battery holder. See Figure 3-21.
1
M3 screws (2)
2
RAID battery assembly
3
RAID controller card
4
RAID battery cable
1
2
3
4
