Installing System Components 189
Installing a Hard-Drive Carrier
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
CAUTION: Combining SATA and SAS hard-drives in the same sled configuration
is not supported.
1 Place the hard-drive carrier into the sled tray and slide into place.
See Figure 3-34.
2 Tighten the thumbscrew to secure the hard-drive carrier in place.
See Figure 3-34.
3 Replace the back cover. See "Installing the Back Cover" on page 151.
4 Replace the sled. See "Installing a Sled" on page 144.
Removing a Hard-Drive From the Hard-Drive Carrier
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized is not covered by
warranty. Read and follow the safety instructions that came with the product.
1 Remove the four screws securing the hard-drive. See Figure 3-35.
2 Lift the hard-drive out of the hard-drive carrier. See Figure 3-35.
1 thumbscrew 2 hard-drive carrier
