Installing System Components 147
MicroSD Card
Removing a MicroSD Card
1 Power down the sled using OS commands or the Baseboard Management
Controller, and ensure that the sled's power is off.
When a sled is powered off, its front-panel power-on indicator is off.
See Figure 1-1.
2 Pull up on the sled release latch at the bottom of the sled to disengage the
sled from the server enclosure. See Figure 3-7.
3 Using the handle, slide the sled out slightly until you have access to the
MicroSD card slot. See Figure 3-7.
4 Press the MicroSD card in to release it from the slot and remove the card.
See Figure 3-7.
Figure 3-7. Removing and Installing a MicroSD Card
1 release latch 2 handle
3 MicroSD card 4 MicroSD card slot
1
2
3 4
