204
Sending a Fax
Adjusting the Document Contrast
Use the Contrast setting to fax your documents lighter or darker.
1 Press Fax from the home screen.
2 Press the Options or Next ( ) button.
3 Press the up/down arrows to select Contrast.
4 Press the left/right arrows to select the contrast mode you want.
• Lighter works well with dark print.
• Normal works well with standard typed or printed documents.
• Darker works well with light print or faint pencil markings.
Adjusting the Document Resolution
Use the Quality setting to improve the output quality of the original or to scan photographs.
1 Press Fax from the home screen.
2 Press the Options or Next ( ) button.
3 Press the up/down arrows to select Send Quality.
4 Press the left/right arrows to select the quality mode you want.
The document types recommended for the resolution settings are described in the table below.
NOTE: Faxes scanned in Super Fine resolution will transmit at the highest resolution supported
by the receiving device.
Mode Recommended for:
Standard Documents with normal sized characters.
Fine Documents containing small characters or thin lines or documents printed
using a dot-matrix printer.
Super Fine Documents containing extremely fine detail. The super fine mode is
enabled only if the remote printer also supports the Super Fine resolution.
See the notes below.
Photo Fax Documents containing shades of gray or photographs.
Color Fax Documents with colors. Sending a color fax is enabled only if the remote
printer supports color fax reception and you send the fax manually. In this
mode, the memory transmission is not available.
