Speaker Assembly
Removing the Speaker Assembly
CAUTION:
Before you begin the following procedure, follow the safety
instructions that shipped with your computer.
1 Follow the instructions in "Before Working on Your Computer" on page 29.
2 Remove the hard-drive cover. See "Removing the Hard Drive" on page 33
for an illustration of the hard drive cover.
3 Remove the WLAN card (see "Removing a WLAN Card" on page 37).
4 Remove the hinge cover (see "Removing the Hinge Cover" on page 53).
5 Remove the keyboard (see "Removing the Keyboard" on page 57).
6 Remove the display assembly (see "Removing the Display Assembly" on
page 65).
7 Remove the palm rest (see "Removing the Palm Rest" on page 79).
8 Remove the four M2 x 3-mm screws from the speaker assembly.
9 Remove the speaker assembly.
