Display
Display Assembly
Removing the Display Assembly
CAUTION:
Before you begin the following procedure, follow the safety
instructions that shipped with your computer.
1 Follow the instructions in "Before Working on Your Computer" on page 29.
2 Remove the hard drive cover. See "Removing the Hard Drive" on page 33
for an illustration of the hard drive cover.
3 Remove the WLAN card (see "Removing a WLAN Card" on page 37).
4 Remove the M2.5 x 8-mm screw that attaches the display assembly to one
corner of the computer.
5 Remove the hinge cover (see "Removing the Hinge Cover" on page 53).
6 Remove the keyboard (see "Removing the Keyboard" on page 57).
