Memory
51
FILE LOCATION: C:\Documents and Settings\sarah_cook\Desktop\Tsing
Ma\SM\A01\EN\Source\memory.fm
DELL CONFIDENTIAL – PRELIMINARY 9/4/09 - FOR PROOF ONLY
Replacing a Memory Module
CAUTION:
Before you begin any of the procedures in this section, follow the
safety instructions that shipped with your computer.
This procedure assumes that you have completed the removal procedure
"Removing a Memory Module" on page 49.
1 Align the notch in the module edge connector with the tab in the
connector slot.
2 Slide the module firmly into the slot at a 45-degree angle, and rotate the
module down until it clicks into place. If you do not feel the click, remove
the module and reinstall it.
NOTE:
If the memory module is not installed properly, the computer may not boot.
No error message indicates this failure.
1 securing clips (2) 2 memory module
1
2
