Template Last Updated - 2/7/2007 Wireless Local Area Network (WLAN) Card
37
DELL CONFIDENTIAL – PRELIMINARY 9/4/09 - FOR PROOF ONLY
Wireless Local Area Network
(WLAN) Card
CAUTION:
Before you begin any of the procedures in this section, follow the
safety instructions that shipped with your computer.
Your computer supports a WLAN card. If you ordered a WLAN card with
your computer, the card is already installed.
Removing a WLAN Card
1 Follow the procedures in "Before Working on Your Computer" on page 29.
2 Turn the computer upside down.
3 Remove the hard drive compartment cover.
4 Rotate each antenna cable until it is positioned away from the WLAN card
and then pull gently on the cable to disconnect it.
