Before Working on Your Computer
31
FILE LOCATION: C:\Documents and Settings\sarah_cook\Desktop\Tsing
Ma\SM\A01\EN\Source\before.fm
DELL CONFIDENTIAL – PRELIMINARY 9/4/09 - FOR PROOF ONLY
8 Slide the battery release latch to the open position. (You may need to hold
the battery release latch in the open position while removing the battery.)
9 Slide the battery out of the battery bay.
10 Turn the computer top-side up, open the display, and press the power
button to ground the system board.
1 battery 2 battery lock
3 battery latch release
3
1
2
