Dell ™ Latitude™ E6400 XFR Service Manual
Page 72
3. Follow the procedures in After Working on Your Computer.
37.19 Removing the SD Card Door
Parts Location
1 Door 2 M2.5 x 5-mm (2)
1. Follow the procedures in Before Working on Your Computer.
2. Open the door to relieve hinge pressure.
3. Remove the handle (see Removing the Handle)
4. Remove the two M2.5 x 5-mm screws from the base assembly
37.20 Replacing the SD Card Door
1. Insert door hinge onto assembly and align the hinge screws to the screw embossments.
2. Replace the two M2.5 x 5-mm screws.
2 1
