Dell ™ Latitude™ E6400 XFR Service Manual
Page 69
1 Door 2 M2.5 x 5-mm (2)
1. Follow the procedures in Before Working on Your Computer.
2. Open the door to relieve hinge pressure.
3. Remove the two M2.5 x 5-mm screws from the bottom of the base assembly
37.12 Replacing the Power Door
1. Insert door hinge onto assembly and align the hinge divots.
2. Replace the two M2.5 x 5-mm screws.
3. Follow the procedures in After Working on Your Computer.
37.13 Removing the VGA Door
Parts Location
2
1
