Dell Latitude E6400 XFR (Mid 2008) - Manual (Page 67)

Dell ™ Latitude™ E6400 XFR Service Manual
Page 67
the wireless circuit. It is advised to check these options as soon as possible. See Replacing the
Wi-Fi Sniffer Card for details.
37.7 Removing the RJ11 Door
Parts Location
1 Door 2 M2.5 x 5-mm (2)
1. Follow the procedures in Before Working on Your Computer.
2. Open the door to relieve hinge pressure.
3. Remove the two M2.5 x 5-mm screws from the bottom of the base assembly
37.8 Replacing the RJ11 Door
1. Insert door hinge onto assembly and align the hinge divots.
2. Replace the two M2.5 x 5-mm screws.
2
1
