Dell ™ Latitude™ E6400 XFR Service Manual
Page 22
3
SCR,PHH,PNH,M2.5X8,STL,BLK
OXD,NYLOK
21900‐10
BASE,DSC,PCMCIA,FPR,BLK,
CYN 20
21000‐03
ASSY,CHASSIS,BASE,DSC, PRC,
PCMCIA, BLK,CYN 2
21106‐02 21030‐01 ASSY,HDL,BLK,CYN 3 57
21902‐03
ASSY,LCD,NON TOUCH,
CMRA+MIC,BLK,CYN 24
21051‐01 SUBASSY,LCD OUTER,BLK,CYN 8
4
SCR,PHH,PNH,M3X3,STL,
BLK OXD,NYLOK
21010‐01 ASSY,DOOR,BTRY,BLK,CYN 8
21012‐01 ASSY,DOOR,HDD,BLK,CYN 4
21106‐03 21014‐01
ASSY,DOOR,DVD,PCMCIA,
BLK,CYN 6 26
21016‐01 ASSY,DOOR,AUDIO,BLK,CYN 4
21018‐01 ASSY,DOOR,VGA,BLK,CYN 4
5 21399
SCR,CAPTIVE,PHH,PNH,M2.5X
9.85,STL,NKL PL
40057
ASSY,GASKET,KEYBOARD,
BRKT, CYN 2 2
6 21381 SCR,THRM,STL
21034‐00 ASSY,HTSK,CU,GROM,CYN 4 4
4 Bottom Access Panel
CAUTION: Before you begin any of the procedures in this section, follow the safety
instructions that shipped with your computer.
4.1 Removing the Bottom Access Panel
1. Follow the procedures in Before Working on Your Computer.
2. Close the display and turn the computer upside down.
3. Remove the twenty-one M2.5 x 5-mm screws that secure the bottom access panel as indicated in the figure
below.
4. Lift the bottom access panel to remove it from the base assembly.
