Dell ™ Latitude™ E6400 XFR Service Manual
Page 65
2. Open the door to relieve hinge pressure.
3. Remove the three M3 x 3-mm screws from the bottom of the base assembly
37.2 Replacing Media Bay Door
1. Insert door hinge onto assembly and align the hinge divots.
2. Insert the three M3 x 3-mm screws and fit securely.
3. Follow the procedures in After Working on Your Computer.
37.3 Removing the AV Door
Parts Location
1 Door 2 M3 x 3 mm (2)
1. Follow the procedures in Before Working on Your Computer.
2. Open the door to relieve hinge pressure.
3. Remove the two M3 x 3-mm screws from the bottom of the base assembly.
2
1
