Indicators, Codes, and Messages
Dell™ PowerEdge™ 2600 Systems Service Manual
Applications, operating systems, and the system itself are capable of identifying problems and alerting you to them. When a problem occurs, a message may
appear on the monitor, or a beep code may sound.
A variety of indicators, codes, and messages can alert you when the system is not functioning properly:
l
System-status indicators
l
Front-panel indicators and features
l
Back-panel indicators and features
l
Power indicator codes
l
Hard-drive indicator codes
l
NIC indicator codes
l
ERA/O Ethernet connector indicator codes
l
Cooling fan indicator codes
l
System beep codes
l
System messages
l
Warning messages
l
Diagnostics messages
l
Alert messages
l
System board LED codes
The system indicators and features are illustrated in
through
. This section also describes each type of message, and lists the possible
causes and actions you can take to resolve any problems indicated by a message. To determine what type of message you have received, read the following
subsections.
System-Status Indicators
The system has indictors that can represent system status. When the bezel is installed, the bezel system-status indicator (see
) signifies when the
system is operating properly or when the system needs attention. A caution code signifies a problem with microprocessors, power supply, system or power-
supply fans, system temperature, hard drives, system memory, expansion cards, or the integrated SCSI controller. When the bezel is off, the system status
indicators on the system (see
) assumes the same functions as the bezel system status indicator.
lists the system's status indicator codes.
Figure 3-1. System-Status Indicators
Table 3-1. System-Status Indicator Codes
Front-Panel Indicators and Features
Back-Panel Indicators and Features
ERA/O Ethernet Connector Indicator Codes
