Removing and Replacing Parts
Dell™ PowerEdge™ 2600 Systems Service Manual
The procedures in this guide require that you remove the cover and work inside the system. While working inside the system, do not attempt to service the
system except as explained in this manual and elsewhere in your system documentation. Always follow the instructions closely. Review all of the procedures in
the System Information Guide.
This section provides servicing procedures for components inside the system. Before you start any of the procedures in this section, perform the following
tasks:
l Perform the procedures described in " External Visual Inspection ."
When there is no replacement procedure provided, use the removal procedure in reverse order to install the replacement part.
Recommended Tools
You need the following items to perform the procedures in this section:
l Key to the system keylock
l #2 Phillips screwdriver
l Wrist grounding strap
System Orientation
Figure 4 -1 shows the rack and tower versions of the system. The illustrations in this document depict the tower version of the system lying on its side.
Figure 4-1. System Orientation
Recommended Tools
System Orientation
Bezel
System Cover
Inside the System
Peripheral Bay
Control Panel
Cooling Shroud
System Fans
Power Supplies
Power Distribution Module
Expansion Cards
ERA/O Card
CD/Diskette Drive
Chassis Intrusion Switch
SCSI Configuration Information
External SCSI Tape Drive
Hard Drives
Activating the Integrated RAID Controller
RAID Controller Card
SCSI Backplane Daughter Card
SCSI Backplane Board
Memory Modules
Microprocessors
System Battery
System Board
CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the components inside the system. See
your System Information Guide for complete information about safety precautions, working inside the computer, and protecting against
electrostatic discharge.
Read the safety information in the System Information Guide.
