Typical installation – Ames Fire & Waterworks 5000RPDA Reduced Pressure Detector Assemblies User Manual
Page 3
3
TYPICAL INSTALLATION
SERIES 2000DCA – 3000DCDC
SERIES 4000RP - 5000RPDA
INDOOR INSTALLATION
OUTDOOR INSTALLATION
INDOOR INSTALLATION
OUTDOOR INSTALLATION
Minimum Clearance 12" (300mm)
Maximum Clearance 30" (762mm)
Minimum Clearance 12" (300mm)
Maximum Clearance 30" (762mm)
Minimum Clearance 12" (300mm)
Maximum Clearance 30" (762mm)
Minimum Clearance 12" (300mm)
Maximum Clearance 30" (762mm)
