Edge Lighting Heat Sink Reflector L-Shaped & Flat Channel User Manual
Page 2
NOTE: Avoid bending the soft strip in sharp horizontal angles
which may damage the LEDs. Use the proper power connectors.
2
C
6: Clean the area thoroughly on the reflector where the soft
strip LED will be installed.
7: Remove the backing from the soft strip LED and firmly press
down making sure there are no air bubbles that can cause
surface irregularities.
7
REFLECTOR
SOFT STRIP LED
D
8: Place the reflector on surface and secure with the
provided #6 screws.
NOTE: Use the provided anchors if mounting reflector to other
surfaces like drywall.
CABINET
REFLECTOR
#6 SCREW
8
