Edge Lighting Regal User Manual
Regal (fluorescent version), Install the fixture, Installation instructions for

SAVE THESE INSTRUCTIONS!
REGAL-F1-_
M2-IND-_
- This product is ETL listed for indoor dry locations.
- This product is wall mounted only.
- This product can mount to either a 4" square electrical box
with round plaster ring or an octagon electrical box.
Installation Instructions for
Regal (Fluorescent Version)
904-REGAL-F1-01
IMPORTANT INFORMATION
1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
Install the Fixture
1:
body to detach the cover.
Remove the two thumb screws on the sides of the fixture
1
A
© 2011 Edge Lighting. All Rights Reserved.
THUMB SCREW
1
COVER
FIXTURE BODY
1
B
2: Squeeze the spring clip ends and remove them from the
inner bracket.
3: Pull the reflector out.
SPRING
CLIP
REFLECTOR
FIXTURE
SPRING CLIP
2
3
INNER
BRACKET
C
CROSSBAR
ASSEMBLY
HEX NUT
FIXTURE BODY
4: Loosen (do not remove) the two M5 set screws on top of the
fixture with the provided 2.5mm Allen wrench.
LOCK WASHER
#8-32 SCREW
CROSSBAR ASSEMBLY
ELECTRICAL BOX HOLE
D
6
4
5
5:
hole.
6: Mount the crossbar
o the electrical box holes with
the provided two #8-32 screws.
Feed the power wires through the crossbar assembly center
assembly t
6
