Installation Instructions for
Night Owl (Plug-In Version)
904-NIGHTOWL-P-02
Install the Fixture
NIGHTOWL-P-_ 1718 W. Fullerton Ave
Chicago, IL 60614
Tel: 773-770-1195
Fax: 773-935-5613
www.edgelighting.com
[email protected]
SAVE THESE INSTRUCTIONS!
- This product is ETL listed for indoor locations.
- This product is for wall mount application.
- This instruction shows a typical installation.
IMPORTANT INFORMATION
A
COVER
1: Remove the cover by sliding it up and then off the backplate.
1
BACKPLATE
B
2: Hold the backplate against the surface where the fixture is
going to be mounted. Level the backplate vertically and mark
the two mounting holes on the surface.
© 2011 Edge Lighting. All Rights Reserved.
MOUNTING
HOLE
MOUNTING
HOLE
BACKPLATE
WALL
2
2
