Edge Lighting Glide Glass, Center Feed User Manual
Page 2
E
MOUNTING PLATE
NUT
POWER WIRE
7:
crossbar threaded nipple and secure it with the nut provided.
Slide the cover and mounting plate center hole onto the
COVER
ELECTRICAL BOX
8:
#8 screws.
Secure the mounting plate to the anchors with the provided
7
F
8
8
#8 SCREW
2
G
H
GLIDE CHANNEL
CANOPY
NOTE:
Determine the fixture height (H), from the bottom of the
channel to the top of the canopy.
H
9: Push each coaxial cable through each cord grip inside the
canopy. Push the tab cord grip to release the cord.
STANDOFF TAB
COAXIAL CABLE
CANOPY
9
I
10: Use the #16 gauge hole of the AWG wire strippers to strip
1/2" of the insulation along with braided wire and inner
wire insulation.
COAXIAL
CABLE
CANOPY
10
WIRE STRIPPER
INSULATION
BRAIDED
WIRE
INNER
INSULATION
BARE WIRE
1/2"
COAXIAL CABLE
