Install the Monorail Adjustable Power Feed
SAVE THESE INSTRUCTIONS!
- This product is ETL listed for indoor dry locations.
- The product is intended to be used with Edge Lighting
Monorail surface mount transformers only.
- This product jumps the power from the transformer to the
Monorail.
IMPORTANT INFORMATION
© 2009 Edge Lighting. All Rights Reserved.
NOTE:
connecting the adjustable power feed (refer to the instructions
provided with each product for further details).
The entire Monorail system should be installed before
A
3/8-24 SET SCREW
1: Unscrew the cap from the power housing.
2: Slightly loosen the 3/8-24 set screw on the cap with the
3/16 Allen wrench provided, DO NOT REMOVE IT.
3/16 ALLEN WRENCH
CAP
1
2
POWER HOUSING
B
3/8-24 SET SCREW
3/16 ALLEN WRENCH
CAP
MONORAIL
3
4
POWER HOUSING
3: Place the power housing onto the Monorail and tighten the
cap to the power housing. Make sure the cap is not cross
threaded.
4: Tighten the 3/8-24 set screw with the 3/16 Allen wrench
provided on the cap firmly for proper power connection.
