CAUTION:

To reduce risk of a burn or electrical shock during

lamping, disconnect the power to the fixture.

4

Install the Lamp

1: Lift the glass shade up to expose the socket assembly.

I

SOCKET ASSEMBLY

J

LAMP

SOCKET

GLASS SHADE

2

3: Carefully lower the glass shade onto the socket assembly.

K

SOCKET

GLASS SHADE

3

1

GLASS SHADE

2: Push the lamp pins completely into the socket holes.

CAUTION:

To reduce risk of a burn or electrical shock during

lamping, disconnect the power to the fixture.

NOTE: Use only fingers and a soft cloth to install the lamps.

Use

MAX

20

Watt, Type Bi-Pin Halogen Lamp.

NOTE:

Use only a clean damp towel to clean the bubble balls. Do

not use any cleaning solutions which may cause the colored
bubble balls to get damaged.
