Humboldt 5000 BLU Light Weight Deflectometer - Manual (Page 47)

MAIN MENU
47
7.3 Subsequent Printing of Test Data
Turn on the device by pressing the ‘START’ button. Then enter the ‘MAIN
MENU’ by pressing the ‘SELECT’ button. Use the ‘SELECT’ button to
move the arrow and select ‘USB STICK’ (‘TERRATEST 4000 USB’ ONLY)
or ‘PRINT FROM SD CARD’ (‘TERRATEST 5000 BLU’ ONLY) from the
menu. Press the ‘START’ button (SET) to enter the test data list. On
‘TERRATEST 4000 USB’ you will then be forwarded to the folder list, named
after the date on which the respective test was performed. Move the
arrow with the ‘START’ and ‘SELECT’ buttons to the folder of your choice.
Open the folder with the ‘PRINT’ button and enter the test data list.
All tests with their consecutive data record number, date and Evd value
will be shown on the display. Move the arrow with the ‘START’ and
‘SELECT’ buttons to select the data record which you would like to print.
Pressing the ‘PRINT’ button will print the corresponding test.
Press the ‘RESET/OFF’ button (EXIT) to return to the ‘MAIN MENU’. Press
the ‘RESET/OFF’ button (EXIT) again to return to the ‘STATUS REQUEST’.
Pressing the ‘START’ button will start the test procedure.
If no test data is saved on the medium, ‘CARD IS EMPTY’ will appear on
the screen for a few seconds; the screen will then return automatically to
the ‘MAIN MENU’.
USB STICK
LANGUAGE
GPS / TIME
INTERNAL MEMORY
SERVICE
EXIT SET
→
→
MAIN MENU
PRINT FROM SD-CARD
LANGUAGE
GPS / TIME
INTERNAL MEMORY
SERVICE
CONNECTION
EXIT SET
→
→
CARD IS EMPTY!
EXIT SELECT
→
13-06-19
13-06-20
13-07-31
→
FOLDER LIST
→
EXIT PRINT
→
001 31/07/13 44,9
002 31/07/13 46,1
003 31/07/13 48,0
004 31/07/13 48,2
005 31/07/13 49,2
→
TEST DATA LIST
→
EXIT PRINT
→
001 31/08/08 44,9
002 31/08/08 46,1
003 31/08/08 48,0
004 31/08/08 48,2
005 31/08/08 49,2
→
TEST DATA LIST
→
‘TERRATEST 4000 USB’
‘TERRATEST 5000 BLU’
