2.3 Basic Package ‘TERRATEST 5000 BLU’
Light Weight Deflectometer 10 kg
corresponding to German standard TP BF-StB Part B 8.3
‘TERRATEST 5000 BLU’ with integrated GPS system and Google ® Maps interface
consisting of:
■ 10 kg loading device with ergonomic weight-catching grip
■ Load plate 300 mm with Bluetooth ® transmission electronics in the sensor dome and integrated
rechargeable battery pack type 8904 7.4V/2.4Ah
■ Testing computer with GPS system,
internal plausibility check and test data comparison,
‘continuous measuring mode’, voice output,
internal memory for up to 2000 tests, on a rolling basis
backlit graphic display for presentation of settlement curves during test,
thermal printer with paper roll, interface for SD memory cards,
integrated rechargeable battery, external control button,
large inspection window enabling operation under adverse weather conditions
■ Connection cable with high-quality push-pull connectors from LEMO for testing computer / load plate
■ User-friendly software ‘TERRATEST 2.0’ with statistical analysis
in accordance with German standard TP BF-StB Part B 8.3
■ SD memory card for saving up to 500 tests
■ Power cable 100 ... 240 V~ / 12 V 1.25 A and
power cable 100 ... 240 V~ / 9 V 2 A with plugs from LEMO
■ Car charger lead 12 V/DC
■
Detailed instruction manual
■ Calibration certificate according to German standard
‘TP BF-StB Part B 8.3 for Soil and Rock Mechanics in Road Constructions’
2.4 Optional Equipment ‘TERRATEST 5000 USB’
■ Loading device with 15 kg drop weight and strengthened spring assembly, calibration certificate
■ ‘CARRELLO 5000’, the mobile testing system, for testing without carrying
■ Transport box ‘VERONA’, made of plywood and an aluminium profile, with integrated handles and
wheels
■ Transport box ‘TORINO’, made of plywood and an aluminium profile, with integrated handles and
wheels, for combined transport of 10 kg basic package and 15 kg loading device
■
Magnetic plate ‘TRETMINE’, for convenient placement of the loading device on the ground
■ Paper rolls for thermal printer
