BaseStation 3200 Advanced Irrigation Controller Manual
Status Colors
The following colors display on the Auto Run screen to indicate the status of programs, master valves, flow meters,
and zones.
Idle (watering done)
Active (watering)
Waiting to water
Soaking
Disabled
Paused
Off or Message (blinking)
Unused
On-Screen Reports
Follow the on-screen instructions to access reports from the main screen.
Note: Refer to Notes, Messages, Alerts, and Logs on page 75 for the complete description of the on-screen reports.
1. Turn the dial to the Auto Run position.
2. Press the NEXT or PREV button to cycle through the report pages.
3. Press the + or – button while on any report page to see more reports or messages for each screen.
Note: Messages can include status or warning messages, or serious controller alarms. Messages are prioritized
with the most serious messages automatically being shown first in the Messages report screen.
Page 35
