Great Plains 3N-4025P Operator Manual - Manual (Page 93)

Great Plains Manufacturing, Inc. Table of Contents Index Adjustments 89
2014-01-29 Table of Contents Index 196-538M
10 and 20 Series Meter Wheel Replacement
Note: Applies only to 10 and 20 Series openers. See
page 80 for 10HD and 25 Series.
Choose the correct seed meter wheel for the type of
seed you will be using. Be sure to use the same wheel
type on all meters.
Meter Wheels Not Interchangeable:
Seed meter wheels for the 20 Series row units are made of a
black color material and are not interchangeable with the
other Great Plains seed meter wheels for other machines. Use
only black wheels in 20 Series row units.
1. Clean out meter. For more information, see
“Cleaning Out Meters” on page 138.
Refer to Figure 112
2.
Push in spring-loaded wheel retainer and make
1 ⁄
4
turn.
Refer to Figure 113
3.
Pull off wheel retainer and spring.
Refer to Figure 114
4.
Pull the seed meter wheel out about
1 ⁄
4
inch (6 mm),
and spin backward to clean out seeds from top
pockets.
5. Remove seed meter wheel using finger holes in
wheel face.
Figure 112: 20P:
Singulator Wheel Retainer
27459
Figure 113: 20P:
Remove Retainer and Spring
27460
Figure 114: 20P:
Remove Meter Wheel
27461
