Great Plains Manufacturing, Inc.
Appendix
171
2014-01-29
196-538M
3N-4010HDP Specifications and Capacities
3N-4010HDP-
-32F
-32TR
-3315
-4810
-49TS
-6475
Operating Width
40 foot (12.2 m)
Swath
a
a. All rows operating; for modified spacings, “Row Spacing Data” on page 176.
480 in.
(1219 cm)
480 in.
(1219 cm)
495
(1257 cm)
480 in.
(1219 cm)
480 in.
(1219 cm)
484 in.
(1229 cm)
Number of Rows
32
32
(16 twin pairs)
33
48
49
(16 twin pairs,
17 splitters)
64
Row Spacing
Nominal
15 in.
(38 cm)
30 in.
(76.2 cm)
15 in.
(38 cm)
10 in.
(25.4 cm)
30 in. pairs
(76.2 cm)
7.5 in.
(19.1 cm)
Tractor
Requirements
b
b. 7.5 in.row spacing, coulters, frame weights and markers increase power requirements over minimum.
275-400 hp (205-300 kW)
Seed Capacity
96 bushels (3883 liters)
Drill Weight
c
c. Weights include frame-mounted coulters and typical press wheels, but not row unit accessories or markers, optional
weights or seed, which can alter the total weight substantially. See “Typical Drill Weights” on page 30 and “Frame
Weight” on page 93.
25220 lbs
(11440 kg)
25220 lbs
(11440 kg)
25365 lbs
(11505 kg)
27540 lbs
(12492 kg)
27685 lbs
(12558 kg)
29860 lbs
(13544 kg)
Max. Additional
d
d. Maximum additional weight kits.
2000 lbs (907 kg)
Hydraulic
Circuits
3 or 4 circuits required: load-sensitive or closed-center 15 to 30 gpm at 2250 psi
Transport Width
14 feet 10
1
⁄
2
inches (4.5 m)
Transport Height
8 foot (2.43 m) without markers, 12 ft. 8 in. (3.86 m) with markers
Transport
Clearance
13
1
⁄
2
inches (34.3 cm)
Operating Height
6 foot 6 inches (1.98 m) without markers, 11 ft. 2 in. (3.40 m) with markers
Length
44 ft. 4 in. (13.51 m) folded, 32 ft. 6 in. (9.91 m) unfolded
Tire Sizes
395/55B16.5 NHS 12-Ply Skid Steer, on 8-Bolt rims
