Page 112

108
3N-40P
Great Plains Manufacturing, Inc.
196-538M
2014-01-29
10HD Press Wheel Spacing
Double V Press Wheel Adjustment
Refer to Figure 148
The double-V closing wheels
can be moved inward
and outward to alter how they close the seed trench and
press soil over the seed.
To move the wheels in toward the center of the trench,
remove one of the
1
⁄
4
in (6.4 mm) spacer bushings
next to the press wheel arm and position it under the
head of the hex head cap screw
.
On wider row spacings the closing wheels can be moved
outward by relocating the spacers to the inside, next to
the press wheel arm
.
Figure 148: 10HD Series
Double-V Press Wheels
23428
1
2
3
4
1
2
3
4
