61
Section 9 Specifications and Capacities
PT1230 Pull-Type Folding Planter 401-069M-A 10/10/12
Great Plains Mfg., Inc.
Section 9
Specifications and Capacities
Mainframe Steel tubing, double bar 5” x 7” x 3/8” wall & 7” x7” x 3/8” wall
Drives Single-pitch roller chain, spring loaded tire, contact driven 2 drives (1 on
each wing)
Transmission End-mounted, No. 40 single-pitch roller chain. Interchangeable sprockets
located near transmission. (1 on each wing)
Hitch Bolt-on with adjustable clevis for leveling.
Tires (6) 9.5L x 15 12-Ply
Transport Height 12’ 10” (on top of folded markers)
Transport Width 15’ 0”
Overall Length 18’ 5”
Shipping Weight 11,400 lbs. (shipping weight is empty with markers)
Row Markers Independent control, automatic alternating, 16” notched blade with depth
band, cast hub with tapered roller bearings, flat fold.
Tractor Requirements 160 Horsepower
Two Remote Outlets
7-Pin Electrical Connector
Row Unit Equipment
Standard
2 bu. Seed Hopper (available w/corn meter or brush meter)
Double disk staggered Openers
4” x 16” Gauge tires
Medium Down Pressure Springs
Optional
70 lbs. Insecticide/Herbicide Hopper with 7” & 14” Diffusers
Heavy Down Pressure Springs
3/4” & Turbo Wavy Coulters
16” Wheel Covers
Seed Lok
®
Terra Tine
Vantage I & Vantage II Fertilizer Coulters
