Great Plains PT1230 AA1062 Operator Manual User Manual
Operator’s manual, Manufacturing, inc

!
Read the operator’s manual entirely. When you see this symbol, the subsequent in-
structions and warnings are serious. Follow without exception. Your life and the lives of
others depend on it.
Cover illustration may show optional equipment not supplied with standard unit.
© Copyright 1999 Printed
P.O. Box 5060
●
Salina, Kansas 67402-5060
Manufacturing, Inc.
401-069M-A
15788
4/15/99
Operator’s Manual
PT1230
Pull-Type Folding Planter
Model
Serial No.
PT1230
AA1062 to AA1079
