60
Section 8 Options
10/10/12 PT1230 Pull-Type Folding Planter 401-069M-A
Great Plains Mfg., Inc.
15728
Insecticide Option
Insecticide & Herbicide Option
Chemical hoppers of 70 lbs/row capacity can be split to hold
35/35 lbs. insecticide and herbicide. Use the 7” band in front
of the closing wheels or place insecticide directly in the fur-
row. Use the 7” or 14” band directly behind the closing
wheels for herbicide application.
For additional information refer to:
•
“Important Safety Information” on page 1
•
“Section 3 Row Unit Operation” on page 19
•
“Section 5 Planting Rate Adjustments” on page 30
•
“Section 7 Maintenance and Lubrication” on page 43
Insecticide Option Bundles
1 x 12 Insecticide in Furrow
6.5 x 12 Insecticide in Furrow
1 x 12 Insecticide 7” Diffuser
Insecticide & Herbicide Option Bundles
Insecticide Furrow & Herbicide 7” 1 x 12
Insecticide Furrow & Herbicide 7” 6.5 x 12
Insecticide Furrow & Herbicide 14” 1 x 12
Insecticide Furrow & Herbicide 14” 6.5 x 12
Insecticide 7” &Herbicide 7” 1 x 12
Insecticide 7” & Herbicide 14” 1 x 12
Note: Not all Insecticide and Herbicide Options are compat-
ible with all closing wheel options. Refer to your Great Plains
dealer.
