Section 7 Maintenance and Lubrication

10/10/12

PT1230 Pull-Type Folding Planter 401-069M-A

Great Plains Mfg., Inc.

Chain Tension

As the chains wear and stretch, you may need to remove
links for proper chain length and tension. Check and re-
place bushings on idlers. For the correct operation of the
planter check all chain routings. Refer to the follow illustra-
tions for chain routings.

Granular Chemical Drive Chain Routing

Transmission Chain Routing

15178

Meter Drive Chain Routing

16871

Reverser Drive Chain Routing

Drive Gauge Wheel Chain Routing

15808

Liquid Fertilizer Chain Routing

16863

16861

16864

16872
