OPERATOR’S MANUAL
Auto Section Control System
11001-1561B-201207
ERROR CODES / 55
ERROR CODES
Various alarm conditions may be presented whenever the system
encounters an abnormal condition or detects a specific alarm. Alarms are
typically in a full screen display describing the alarm and, dependent upon
the alarm type, may give instructions on how to fix the alarm. Each alarm
type has an associated alarm number .
Some alarms require a specific action before the alarm condition will cease.
In these cases, instructions are indicated on the alarm display.
Other alarms can be acknowledged by pressing the Alarm Cancel button
of ESC key on the IntelliAg virtual terminal.
For any failure that persists, contact DICKEY-john Technical Support at
1-800-637-3302
Error
Codes
Error Probable Cause Corrective Action
100 ECU Control Module
Lost
COMMUNICATION WITH AN ACTIVE
MODULE HAS FAILED
1. Damaged CAN or module harness.
2. Blown module harness fuse.
3. Defective module.
1. Identify missing module in the Module
Configuration list. Inspect CAN/module harness
of the missing module for damage. Repair or
replace harness.
2. Inspect module harness fuse, replace if
necessary.
3. Identify missing module in the Module
Configuration list. Inspect missing module for
damage or replace.
101 ECU Control Module
Intermittent
1. A module that had previously failed
communication has come online.
1. Inspect harness connections to this module.
102 GPS Signal Quality Low GPS signal quality has degraded below a usable
level.
1. Check GPS antenna corrections.
2. Inspect GPS harness for damage.
3. Check GPS communication settings.
4. Inspect GPS receiver for damage.
103 Internal Data Storage
Space Low
Internal data storage is low on free space. 1. Clear old coverage lags.
2. Delete unused fields.
3. Delete unused farms.
4. Delete unused clients.
104 Internal Data Storage
Space is Critical
Internal data storage is low on free space. 1. Clear old coverage lags.
2. Delete unused fields.
3. Delete unused farms.
4. Delete unused clients.
105 In Setup with System
Running
Detected implement controller running and not in
Ready state.
1. Complete setup operations.
2. Complete Task Selection.
3. Return to the Work Screen.
200 Setting Change Active System settings changed and operating began
before system could initialize.
1. Stop operating by lifting implement, turning
master switch off, or stopping.
2. Restart the system.
